| Products |
Size |
O.D |
O.D
Tolerance |
Wall
th'k |
Wall
Tolerance |
Length |
Length
Tolerance |
| Tube |
1/4" |
6.35mm |
±0.10mm |
1.194mm |
±0.10mm |
100m |
0%
~ 2% |
| 3/8" |
9.53mm |
±0.10mm |
1.574mm |
±0.10mm |
|
| 1/2" |
12.70mm |
±0.12mm |
1.574mm |
±0.10mm |
|
| 3/4" |
19.05mm |
±0.12mm |
1.574mm |
±0.10mm |
|
| 1" |
25.40mm |
±0.20mm |
1.574mm |
±0.10mm |
|
| 1-1/2" |
40.00mm |
±0.25mm |
2.184mm |
±0.15mm |
|
| Pipe |
1/2" |
21.34mm |
±0.13mm |
2.768mm |
±0.25mm |
3m |
0%
~ 1% |
| 3/4" |
26.67mm |
±0.25mm |
2.870mm |
±0.25mm |
|
| 1" |
33.40mm |
±0.38mm |
3.378mm |
±0.38mm |
|
| 1-1/2" |
50.50mm |
±0.51mm |
3.370mm |
±0.38mm |
|
| 2" |
60.33mm |
±0.51mm |
3.911mm |
±0.38mm |
|
|
| Products |
Size |
O.D |
O.D
Tolerance |
Wall
th'k |
Wall
Tolerance |
Length |
Length
Tolerance |
| Tube |
Ø6mm |
6mm |
±0.10mm |
1mm |
±0.10mm |
100m |
2% |
| Ø8mm |
8mm |
±0.10mm |
1mm |
±0.10mm |
|
|
| Ø10mm |
10mm |
±0.12mm |
1mm |
±0.12mm |
|
|
| Ø12mm |
12mm |
±0.12mm |
1mm |
±0.12mm |
|
|
| Level Pipe |
25.5
X 21 |
25.50mm |
±0.20mm |
2.25mm |
±0.10mm |
|
|
|
